SMD 2835 LED Chip 9V 18V 36V 54V 72V White Wide Range 120° View Angle

Name: SMD 2835 LED Chip 9V 18V 36V 54V 72V White Wide Range 120 View Angle
Brand: HuanYu Dream
Price: 1 USD

China SMD 2835 LED Chip 9V 18V 36V 54V 72V White Wide Range 120° View Angle wholesale

Current : 100mA

Voltage : 9V

Brand Name : HuanYu Dream

Model Number : HY-High Voltage White Series

Certification : Rohs

Place of Origin : China

MOQ : 4000pcs

Price : Negotiable

Payment Terms : T/T,Paypal,Ali Pay

Supply Ability : 500Kpcs/Day

Delivery Time : 7-9 Work Days

Packaging Details : 4000pcs/Reel

Power : 1W

Package : HY-2835W-9V

Color : White

Lumen : 135-145LM

Warranty : 3-years

Viewing Angle(°) : 120°

Contact Now

2835 SMD LED Chip White Colors 9V 18V 36V 54V 72V

Product Features

2835/3030/5730 are available
3V 9V 18V 36V 54V 72V are available
Available in Red, Blue, Green,White
Compact SMD design with high Voltage
Extremly wide viewing angle
Super long lifetime:>30000hrS

Product Specifications(Phosphor red)

Models	HY-2835W65-9V1S HY-2835W120-9V2S	HY-2835W50-18V	HY-2835W30-36V	HY-2835W20-54V	HY-2835W15-72V
Electronic power	0.5W/1W	1W	1W	1W	1W
CCT	2700-6500K
VF	9V	18V	36V	54V	72V
IF	50mA/100mA	50mA	30mA	20mA	15mA
LUMINUOUS EFF	70-80lm/125-145lm	130-140lm	130-140lm	130-140lm	130-140lm
WHOLE SIZE	2.8*3.5mm
CHIP Brand	Sanan/Epistar
VIEW ANGLE	120°
Warranty	3 years

Dimension(Units:mm; mark is cathode)

SMD 2835 LED Chip 9V 18V 36V 54V 72V White Wide Range 120° View Angle

Application

Smart Lighting
Pilot Lamp
Commercial Illuminate : Advertising words, light box
Decorative Lighting: Light Strip
Other illuminations

SMD 2835 LED Chip 9V 18V 36V 54V 72V White Wide Range 120° View Angle
