Surface Mount LEDs 2835 Smd Led Chip Red 3V 150mA 0.5W for Outdoor warning lights
Led SMD 2835 Red Introduction
2835 SMD LED Diode, Plcc-2 Surface Mount SMT 2835,Gold wire, copper bracket, Epistar chip, long lifespan, Super high brightness, Wide Viewing Angle: 120 Degrees
Parameters: DC 3.0V-3.2V Volt 150mA; 2.0-2.2v 60mA (Red/Infared Red), Size: 2.8 X 3.5 X 0.7 (mm), Anode and Cathode Polarity: Please Refer to A+ page, Surface-Mount Device, Pack of 100 Pieces LED diode(mini Chip)
CUSTOMIZE YOUR LIFE: Light up your dashboard with a unique pop of color unlike anyone else. Replace the LEDs in your car dash, truck, motorcycle instrument cluster, xbox controller, or anywhere else. Outstanding value for brightness.
ENDLESS POSSIBILITIES: 4000's of creative uses, whether you want to light up your car, truck, boat, house, our high quality Surface Mount SMD PLCC-2 2835/3030/5050/3528/7070 LEDs are just what you need. The project ideas are endless, and we love seeing new ways our customers use our LEDs. Send us your application photos!
LIFETIME GUARANTEE: We sell products that last. Our rock-solid guarantee means we'll replace you it if there's ever a problem. Pass it on to the next generation with confidence.
Led SMD 5730 Red Dimension (Tolerance:+/-0.1mm. Unit:mm)
Led SMD 2835 Red Details
Initial Electrical/Optical Characteristics (TA=25±5ºC)
| Symbol | Item | Units | Min. | Typ. | Max. | Test Conditions |
| VF | Forward Voltage | V | 2.0 |
| 2.4 | IF=150mA |
| IR | Reverse Current | uA | - | - | 5 | VR=5V |
| 2θ½ | Viewing Angle | º | - | 120º | - | IF=150mA |
| ø | Luminous flux | lm | 20 |
| 25 | IF=150mA |
| IV | Light intensity | mcd | 6500 |
| 8000 | IF=150mA |
| WLD | Dominant wavelength | nm | 620 | 625 | 630 | IF=150mA |
Absolute Maximum Ratings (TA=25±5ºC)
| Item | Symbol |
Absolute Maximum Rating |
Unit |
| Forward Current | IF | 150 | mA |
| Pulse Forward Current | IFP | 200 | mA |
| Reverse Voltage | VR | 5 | V |
| Power Dissipation | PD | 600 | mW |
| Operating Temperature | Topr | -40ºC To +85ºC | °C |
| Storage Temperature | Tstg | -40ºC To +85ºC | °C |
| Soldering Temperature | Tsld | Reflow Soldering: 260ºC Hand Soldering : 350ºC | for 10sec. for 3sec. |
Led SMD 2835 Red Application
- High Power LED Lamp
- Indoor lighting: Fluorescent lamp, tube
- Commercial Illuminate and displays: Advertising words, light box
- Decorative Lighting: Light Strip
- Other illuminations
- Led back lighting
